Phtovoltaic Inverter

CYP series(can be parallel)Hybrid Solar Charge Inverter

  • Product ID:Phtovoltaic Inverter
  • WhatsApp & WeChat:+8613868719385
  • Phone: +8613868719385
  • Tel: +86 577 27880251
  • Email: energy@meiyuyuan.com

CYP series is a new all-in-one hybrid solar charge inverter, which integrates solar energy storage & means charging energy storage and AC sine wave output.

1.Anti-backflow grid connection function, support for inverter and mains power hybrid output,

support for use without battery, can be set up for on-grid power generation.

2.Two output modes: mains bypass and inverter output; uninterrupted power supply.

3.Available in 4 charging modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar

hybrid charging.

4.Advanced MPPT technology with an efficiency of 99.9%.

5.Designed with a LCD screen and 3 LED indicators for dynamic display of system data and operating status.

6.With time slot control, you can set the priority of using the mains and battery according to the time slot in conjunction with the local peak and valley tariffs.

7.Power saving mode available to reduce no-load loss.

8.Intelligent variable speed fan efficiently dissipate heat and extend system life.

9.Lithium battery activation by PV solar or mains, allowing access of lead-acid battery and lithium battery.

10.360 ° all-around protection with a number of protection functions.

11.Complete protections, including short circuit protection, over voltage and under voltage protection, overload protection, reverse protection, etc.
